A2-70 Allen Bolt and Stainless Steel Allen Head Screws Supplier
Stainless Steel allen bolts manufacturer in India produce the allen bolts in different standards, dimensions and material grades. RIMCO FASTENER a leading producer of the ss 304 allen bolt and other material grades in larger quantities. The allen bolts are special that they have a grooved head that can be fitted with a special tool called the allen key. The sscskallen bolt is made in the 304 material for most uses
Allen Cap Bolt
Stainless Steel Allen Bolts
Check Stainless Steel Button Head Allen Bolts price list, SS 304 allen bolt Trader, Distributor of Stainless Steel Countersunk Allen Bolts in Mumbai
There are other material grades that are used to produce different specifications of the bolts such as the a2-70 allen bolt. Each different specification applies for different applications, temperatures and stress levels. There are also different types such as the Stainless Steel Allen Cap Screws which can be driven into a bolt hole without the need for a nut to fix them. The bolt ranges in diameter and length based on the specification, application and the standards. The Stainless Steel allen head screws are used with stainless steel applications. Most uses are seen in engine parts, tools and equipment components where the head is sunk into the surface while the allen key can access the bolt head. The different types such as the Stainless Steel button head allen bolts are used to cater different needs. The button head sticks out of the surface to make it easy to access while other types such as the Stainless Steel countersunk allen bolts is sunk into the surface to keep the surface flat. Please contact us for more information and pricing of the allen bolts.
An Allen Cap Bolts is a type of strung fastener with an outside male string. Allen Cap Bolts are firmly identified with screws. Individuals misjudge the contrast between Allen Cap Bolts and screws. Allen Cap Bolts are regularly used to make a Bolted joint. This is a blend of the nut applying a hub clipping power and furthermore the shank of the Allen Cap Bolts going about as a dowel, sticking the joint against sideways shear powers. Therefore, numerous Allen Cap Bolts have a plain unthreaded shank (called the grasp length) as this makes for a superior, more grounded dowel. The nearness of the unthreaded shank has frequently been given as normal for Allen Cap Bolts versus screws, however this is coincidental to its utilization, as opposed to characterizing.
Allen Bolts material specification chart
Save upto 10% on SS CSK Allen Bolt in Mumbai, ready Stock of Stainless Steel Allen Head Screws, Stainless Steel Button Head Allen Bolts, Allen Cap Bolts
| Standard | ISO 4017, DIN931, GB5783, DIN, ASTM, ANSI, JIS, EN, AS |
|---|---|
| DIN Standard | B.S. DIN933 DIN931 DIN934 DIN912 DIN603 DIN6923 |
| Stainless Steel Allen Bolts Size | M2 – M100 |
| Stainless Steel Allen Bolts Diameter | M3-M60 |
| Stainless Steel Allen Bolts Length | 6mm-500mm |
| Head | Hex, Square, Round, Hex flange, Flat, T-head & Triangular etc |
| Neck type | Hex, Square, Triangular, Oval & Knurled etc |
| Dimensions | ASME B18.6.3 **Exception: screws 6 inches and shorter are fully threaded. |
| Stainless Steel Allen Bolts Material | 18-8 Stainless Steel, stainless steel ss 304/ SS316 A2/A4, SS201, SS303, SS304, SS316, SS316L, SS904L, A2-70; A4-70; A4-80 |
Frequently Used Stainless Steel Allen Bolts Types
Dimension Table of Allen Cap Bolts
One of India’s largest Stainless Steel Allen bolts Manufacturer in India, Allen Cap Bolts, socket cap allen bolts Stockist, Check stainless steel Allen Cap Screws Dimension
One of India’s largest Stainless Steel Allen bolts Manufacturer in India, Allen Cap Bolts, socket cap allen bolts Stockist, Check stainless steel Allen Cap Screws Dimension
| Metric (d) | Thread Length (b) | Head diameter | Head high | Socket width | Socket Depth (t min.) | ||||
|---|---|---|---|---|---|---|---|---|---|
| (dk max.) | (dk min.) | (k max.) | (k min.) | (s Nom.) | (s min.) | (s max.) | |||
| M 3 | 18,0 | 5,5 | 5,32 | 3,0 | 2,86 | 2,5 | 2,52 | 2,58 | 1,3 |
| M 4 | 20,0 | 7,0 | 6,78 | 4,0 | 3,82 | 3,0 | 3,02 | 3,08 | 2,0 |
| M 5 | 22,0 | 8,5 | 8,28 | 5,0 | 4,82 | 4,0 | 4,02 | 4,095 | 2,5 |
| M 6 | 24,0 | 10,0 | 9,78 | 6,0 | 5,7 | 5,0 | 5,02 | 5,14 | 3,0 |
| M 8 | 28,0 | 13,0 | 12,73 | 8,0 | 7,64 | 6,0 | 6,025 | 6,14 | 3,5 |
| M 10 | 32,0 | 16,0 | 15,73 | 10,0 | 9,64 | 8,0 | 8,025 | 8,175 | 4,0 |
| M 12 | 36,0 | 18,0 | 17,73 | 12,0 | 11,57 | 10,0 | 10,025 | 10,175 | 5,0 |
| M 14 | 40,0 | 21,0 | 20,67 | 14,0 | 13,57 | 12,0 | 12,032 | 12,212 | 6,0 |
| M 16 | 44,0 | 24,0 | 23,67 | 16,0 | 15,57 | 14,0 | 14,032 | 14,212 | 7,0 |
| M 20 | 52,0 | 30,0 | 29,67 | 20,0 | 19,48 | 17,0 | 17,05 | 17,23 | 8,0 |
| M 24 | 60,0 | 36,0 | 35,61 | 24,0 | 23,48 | 19,0 | 19,065 | 19,275 | 10,0 |
| M 27 | 66,0 | 40,0 | 39,61 | 27,0 | 26,48 | 19,0 | 19,065 | 19,275 | 12,0 |
| M 30 | 72,0 | 45,0 | 44,61 | 30,0 | 29,48 | 22,0 | 22,065 | 22,275 | 13,5 |
| Diameter | 3 | 4 | 5 | 6 | 8 | 10 | 12 |
| Pitch | 0.5 | 0.7 | 0.8 | 1.0 | 1.25 | 1.5 | 1.75 |
| Head Height | 3.5 | 4 | 5 | 6 | 8 | 10 | 12 |
| Head Diam | 5.5 | 7.5 | 8.5 | 10 | 13 | 16 | 18 |
| Key Size | 2.5 | 3 | 4 | 5 | 6 | 8 | 10 |
Allen Bolts Weight Chart
Supplier of SS 304 allen bolt in India, Save up to 10% on stainless steel Allen Cap Screws in Mumbai, Buy from Trusted Stockist of allen head cap bolts, stainless steel countersunk allen bolts, a2-70 allen bolt Manufacturer in India, Check Weight chart of Allen Cap Bolts
| Chemical Composition of Stainless Steel 304 Fasteners | ||||||||||
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
| Stainless Steel 304 | min. | - | - | - | - | - | 18 | - | 8 | - |
| max. | 0.08 | 2 | 0.75 | 0.045 | 0.03 | 20 | 10.5 | 0.1 | ||
| Stainless Steel 304L | min. | - | - | - | - | - | 18 | - | 8 | - |
| max. | 0.03 | 2 | 0.75 | 0.045 | 0.03 | 20 | 12 | 0.1 | ||
| Stainless Steel 304H | min. | 0.04 | - | - | - | - | 18 | - | 8 | - |
| max. | 0.1 | 2 | 0.75 | 0.045 | 0.03 | 20 | 10.5 | |||
| Stainless Steel 304 Fasteners Equivalent Grade | ||||||||||
| AISI Grade Equivalent | JIS Equivalent | Stainless Steel Notation | EN/DIN Numerical Equivalent | UNS | EN/DIN Symbolical Equivalent | |||||
| designation | ||||||||||
| AISI 304 | SUS304 | SS 304 | EN 1.4301 | UNS S30400 | X4CrNi18-10 | |||||
| AISI 304L | SUS304L | SS 304L | EN 1.4307 | UNS S30403 | X2CrNi18-9 | |||||
| AISI 304H | SUS304H | SS 304H | EN 1.4948 | UNS S30409 | X2CrNiN18-10 | |||||
| Stainless Steel 304 Fasteners Mechanical Properties | ||||||||||
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | ||||||
| Rockwell B (HR B) max | Brine-ll (HB) max | |||||||||
| Stainless Steel 304 | 515 | 205 | 40 | 92 | 201 | |||||
| Stainless Steel 304L | 485 | 170 | 40 | 92 | 201 | |||||
| Stainless Steel 304H | 515 | 205 | 40 | 92 | 201 | |||||
| AISI 304 Stainless Steel Fasteners Physical Properties | ||||||||||
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity(n.m) | ||||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | ||||||
| Stainless Steel 304/L/H | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 | |
ALLEN CAP BOLT used in Petroleum Industry
ALLEN CAP BOLT used in Aerospace Industry
ALLEN CAP BOLT used in Chemical Industry
ALLEN CAP BOLT used in oil & Gas Industry
ALLEN CAP BOLT used in Nuclear Energy Sector
ALLEN CAP BOLT used in Automotive Industries
Exporter of ALLEN CAP BOLT in India
Exporter of ALLEN CAP BOLT in Mumbai
Manufacturer of ALLEN CAP BOLT in India
Manufacturer of ALLEN CAP BOLT in Mumbai
Stockiest of ALLEN CAP BOLT in India
Stockiest of ALLEN CAP BOLT in Mumbai
ALLEN CAP BOLT exporter
ALLEN CAP BOLT manufacturer
ALLEN CAP BOLT stockiest
ALLEN CAP BOLT supplier
ALLEN CAP BOLT supplier in India
ALLEN CAP BOLT supplier in Mumbai
ALLEN CAP BOLT supplier in Australia
ALLEN CAP BOLT supplier in Bahrain
ALLEN CAP BOLT supplier in Bangladesh
ALLEN CAP BOLT supplier in Brazil
ALLEN CAP BOLT supplier in Canada
ALLEN CAP BOLT supplier in Germany
ALLEN CAP BOLT supplier in Iran
ALLEN CAP BOLT supplier in Kuwait
ALLEN CAP BOLT supplier in Malaysia
ALLEN CAP BOLT supplier in Mexico
ALLEN CAP BOLT supplier in The Netherlands
ALLEN CAP BOLT supplier in new Zealand
ALLEN CAP BOLT supplier in Nigeria
ALLEN CAP BOLT supplier in Qatar
ALLEN CAP BOLT supplier in Saudi Arabia
ALLEN CAP BOLT supplier in Singapore
ALLEN CAP BOLT supplier in south Africa
ALLEN CAP BOLT supplier in Sri Lanka
ALLEN CAP BOLT supplier in Turkey
ALLEN CAP BOLT supplier in UAE
ALLEN CAP BOLT supplier in united kingdom
ALLEN CAP BOLT supplier inThe United States
ALLEN CAP BOLT supplier in Venezuela
| MARKING AND PACKING Products are packaged to ensure that there is no damage during transit. In the case of exports, standard export packaging is done in wooden cases. All pipes are marked with Grade, Lot No, Size, Degree, and our trademark. On special requests, we can also, make custom marking on our products. QUALITY ASSURANCE At RIMCO FASTENER, all fasteners are subject to strict inspection at each stage of the production process, from starting material purchasing to product dispatch. They are visually examined for conformity to ASTM, ASME, MSS, DIN, EN, and JIS codes and standards. Upon request, official certified Inspection Agencies can be called in to witness the material reports, dimensions, and quality conformity of products. TEST CERTIFICATES Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report SHIPPING POLICY Delivery time and delivery dates are based on the "type and quantity" of steel ordered. Our sales team will provide a delivery schedule when quoting to you. On rare occasions the delivery schedule may change so please check with our sales department when placing any orders. Orders will be sent out within 2-3 business days and may take up to 5-10 business days in transit. If the fastener is out of stock, orders may take up to 2-4 weeks to ship. RIMCO FASTENER will notify the buyer if this situation occurs. USES & APPLICATION RIMCO FASTENER takes immense pleasure in introducing itself as one of the leading Manufacturers & exporters of high-quality fasteners to meet the customer's ultimate requirements in the fields. |
